ZAR61 Suite

Features

  • 2 rows that can seat 6 persons forward running;
  • anchor forepeaks and afterpeaks;
  • back peak with the mooring accessories;
  • front sun bathing bed convertible into a double bed (cm 150 x 195) with extension as an optional;
  • wide stem dinette with a table as an optional;
  • wide back peak;
  • two side peaks in the stem sides;
  • 160 x 195 back sunbathing bed (with the back rest in the horizontal position);
  • wide back peak;
  • wide front peak;
  • two-seater console with a hydraulic wheelhouse, stainless steel rudder, 1 internal compartment door, an object holder and two peaks under the driver’s couch and under the front seat. Reclining driver’s couch with pantograph movement;
  • foldaway stainless steel ascent ramp and double VTR bridge;
  • bilge pump;
  • repairs kit;
  • inflating device;
  • a pair of paddles;
  • 7 stainless steel handles for passengers safety;
  • driver’s couch with double position (sitting up and down);
  • 1 reticular polypropylene fuel tank (about 200 litres) according to standards CE;
  • 4 handling handles;
  • 4 stainless steel bollards;
  • perimetric double millpond;
  • polished stainless steel 6,5 Kg anchor;
  • anchor-winch nose with stainless steel bow;
  • 3 stainless steel eyebolts for hangers.

Technical Data

  • Static self emptying
  • Homologation “CE cat. “B”
  • Length m 6.07
  • Width m 2.54
  • Internal walking length m 6.00
  • Internal walking width m 1.99
  • Intertubular width m 1.49
  • Tubular diameter cm 53
  • N. tubular compartments n. 6
  • Seating capacity n. 12
  • Net dinghy weight (with standard equipment, without liquids and motor) ± 10% variable datum kg 750
  • Maximum power applicable kW 133/HP 180
  • Minimum power applicable kW 85
  • (minimum performance) HP 115
  • Power recommended kW 96/133
  • (average performance) HP 130/180
  • Engine shaft length L
  • Max. weight installable motors kg 400
  • CE certification with “B” design category and CE type testing. (A+a form).

Optional Equipment

  • Stainless steel roll-bar
  • Roll-bar installation with running lights, anchorage lights, horn and wiring
  • Beacon ready installed on roll-bar/console
  • Sunbed extension
  • Prow complete table
  • Auxiliary engine support
  • Total night cover
  • Partial night cover
  • Console cover
  • Seat cover
  • Left stern deck with folding ladder
  • Right stern deck
  • Shower Complete with surge tank, tank in prow, outdoor embarkation and installation
  • Complete dingy heuling belt kit for launch/accommodation
  • Anchor windlass installed with motor, cable, chain and double controls (in console and anchor housing)
  • Eletric panel
  • Wake board kit complete with counterplates
  • Eletric refrigerator (12/24V)
  • Flexi-teak for cockpit
  • Felxi teak for the bridges + covers (4pz)
  • Felxi teak for the bridges (2pz)
  • Flexi-teak installation
  • Nautical camping tent
  • Sunroof 3 arch
  • Rear telescopic sun-cover for roll-bar
  • Prow sunroof (rear telescopic sun-cover extension)
  • Side canopy(1) for telescopic sun-cover
