ZAR47

Features

  • 2 rows that can seat 4 persons forward running;
  • front peak for the anchor with the side opening door;
  • anchor forepeak;
  • front sun bathing bed convertible into a double bed (cm 130 x 190) with extensions as an optional that includes dunnages and pillows, the middle dunnage with a stainless steel leg can be used as a table;
  • 130 x 130 back sunbathing bed (with back rest in the horizontal position);
  • wide back peak; • wide front peak;
  • one-seater console with mechanical wheelhouse, stainless steel rudder, 1 internal compartment with door, 1 peak under the front seat;
  • foldaway stainless steel ascent ramp and VTR bridge;
  • 5 stainless steel handles for passengers safety;
  • 4 handling handles;
  • 4 stainless steel bollards;
  • perimetric double millpond;
  • anchor-winch nose;
  • 5 stainless steel (4 eyebolts for hangers);
  • repairs kit;
  • inflating device;
  • a pair of paddles.

Technical Data

  • Static self emptying
  • Homologation “CE cat. “C”
  • Length m 4.86
  • Width m 2.32
  • Internal walking length m 4.80
  • Internal walking width m 1.80
  • Intertubular width m 1.28
  • Tubular diameter cm 52
  • N. tubular compartments n. 6
  • Seating capacity n. 8
  • Net dinghy weight(with standard equipment, without liquids and motor) ± 10% variable datum kg 380
  • Potenza max. applicabile kW 86/CV 115
  • Maximum power applicable kW 85/HP 115
  • Minimum power applicable kW 30 HP 40
  • Power recommended kW 30/67 HP 40/90
  • Engine shaft length L
  • Max. weight installable motors kg 220
  • CE certification with “C” design category and CE type testing. (A+a form).

Optional Equipment

  • Stainless steel about 100 l tank
  • Tank installation in accordance with EC standards
  • Reticular polyethylene fuel tank of about 100 lt.
  • Reticular polyethylene fuel tank installation in accordance with EC standards
  • Overturning stainless steel roll-bar
  • Roll-bar installation with running lights, anchorage lights, horn and wiring
  • Bilge pump installation
  • Beacon ready installed on roll-bar/console
  • Electric panel
  • Auxiliary engine support
  • Prow sunbed extension with limber board and table legs
  • “Stand up” cushion
  • Total night cover
  • Partial night cover
  • Console cover
  • Shower Complete with surge tank, tank in prow,outdoor embarkation and installation
  • Complete dingy heuling belt kit for launch/accommodation
  • Prow stuffing (n 3 piece)
